Semi-Automatic Aluminum Beer Can Filling Machine
- Inner stretching membrane and PE paper and outer steel
- frame, and other packaging for shipping.
1. Main tanks, vessels and machines will be packaged with - plastic paper firstly then with painted steel frames.
2. All spare parts, accessories and fittings will be packaged - with wooden box.
3. All items wrapped with soft package for protection.
Semi-Automatic Aluminum Beer Can Filling Machine for Carbonated Beverage
HULK Brewtech company is your one-stop system solution for your brewery Setting Up project.
The Semi-automatic Can filling machine is customized for homebrew hobbies, pubs, pilot beer filling requirements.
The Best Solution for Beer Can Fill Applications
If you are canning your tasty beers from tank to a can, don’t miss out on this smart Semi-automatic can filling machine, desktop type, small size, automatic, and it’s really cost-effective.
1. Dimension=636*360*202mm, Gross weight=36kg
2. Capacity: 4pcs/min (330ml) or 3pcs/min(500ml)
3. Power supply:
Singel Phase AC 110V~230V 50Hz/60Hz(customized)
4. Power consumption: 370W
5. Material is 304 Stainless steel
6. Size of can in default:
Height Adjustable (customized)
![]() | ![]() |
![]() | ![]() |
1 | Beer Source Pressure | 0.08-0.15MPa (12-22psi) |
2 | Beer Temperature | -1℃— 0℃ |
3 | Beer CO2 Content | <2.7 |
4 | CO2 Source Pressure | 0.05-0.08MPa (9-12psi) |
5 | Power Supply | Single Phase, AC 110V~230V 50Hz/60Hz |
6 | Glycol Water Flow Rate | 100L/H |
7 | Glycol Water Temperature | -2C ~ -1C |
1. Machine working procedure:
Put Can into position -> Charge CO2 -> Filling -> Stop when liquid level comes to the level sensor
2. Attention
CIP Cleaning is very important once finished filling work. Please connect CIP liquid into the Beer inlet to finalize the cleaning job before you power off the machine.
> Relative product
Beer Can Capping Machine:
1. Dimension=0.30×0.50×0.90m, gross weight=36kg
2. Capacity: 10pcs/min
3. Power supply: Singel Phase 220V 50Hz is default (customized)
4. Power consumption: 370W
5. Material is 304 Stainless steel
6. Size of can in default:
D55mm, Height=115mm/ 170mm (customized)
![]() | ![]() |
![]() | ![]() | ![]() |
![]() | ![]() | ![]() |
![]() | ![]() | ![]() |
Yes, HULK designers will assist in initial space planning by providing AutoCAD(2D) and Solidworks (3D) layouts of our brewing equipment that can be coordinated into your floor plan development.
We can feedback with draft drawing within 2 working days.
